PMA-545G1+ Mini-Circuits IC RF AMP CEL 400MHZ-2.2GHZ 8QFN
PMA-545G1+ Images
PMA-545G1+ Images
PMA-545G1+
  • Manufacturer: Mini-Circuits
  • Category: RF-IF and RFID~RF Amplifiers Package/Case: 8-VQFN Exposed Pad
  • Description: IC RF AMP CEL 400MHZ-2.2GHZ 8QFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
PMA-545G1+ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
PMA-545G1+ Specifications:
  • MfrPart.: PMA-545G1+
  • Mfr: Mini-Circuits
  • Description: IC RF AMP CEL 400MHZ-2.2GHZ 8QFN
  • Product Category: RF-IF and RFID~RF Amplifiers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • Frequency: 400MHz ~ 2.2GHz
  • P1dB: 22.6dBm
  • Gain: 26.1dB
  • NoiseFigure: 1.2dB
  • RFType: Cellular, GSM, GPS, ISM, LTE, WCDMA
  • Voltage-Supply: 4.8V ~ 5.2V
  • Current-Supply: 158mA
  • TestFrequency: 2.2GHz
  • MountingType: Surface Mount
  • Package/Case: 8-VQFN Exposed Pad
  • PMA-545G1+ Mini-Circuits, IC RF AMP CEL 400MHZ-2.2GHZ 8QFN, RF-IF and RFID~RF Amplifiers
