Mini-Circuits has expanded our selection of low-temperature co-fired ceramic (LTCC) bandpass filters with 4 new models in our BFCN series to meet your needs. These new models come housed in tiny 1206 ceramic packages with wraparound terminations, saving board space and minimizing the effect of parasitics. They all offer exceptional reliability with operating temperature range from -55 to +100 ℃, and excellent repeatability of performance.

Model BFCN-1860+ has a passband from 1580 to 2200 MHz. This model provides 2.0 dB passband insertion loss, 20 dB upper/lower stopband rejection, and RF input power handling up to 2.5W. Available from stock starting at $3.95 each (qty. 20-49).

Model BFCN-2500+ has a passband from 2100 to 2900 MHz. This model provides 2.0 dB passband insertion loss, 28 dB lower stopband rejection, 24 dB upper stopband rejection, and RF input power handling up to 2.5W. Available from stock starting at $3.95 each (qty. 20-49).

Model BFCN-3700+ has a passband from 3000 to 4600 MHz. This model provides 1.9 dB passband insertion loss, 20 dB upper/lower stopband rejection, and RF input power handling up to 2.5W. Available from stock starting at $3.95 each (qty. 20-49).

Model BFCN-5200+ has a passband from 4250 to 6300 MHz. This model provides1.8 dB passband insertion loss, 23 dB lower stopband rejection, 21 dB upper stopband rejection, and RF input power handling up to 2.5W. Available from stock starting at $3.95 each (qty. 20-49).

Mini-Circuits BFCN-series LTCC bandpass filters are available off the shelf for immediate shipment. Order today and have them in hand as soon as tomorrow!
